Infrared Sensor Ceiling Mounted Presence Detector for Auto-Door Control System

Infrared Sensor Ceiling Mounted Presence Detector for Auto-Door Control System

Features:

• Power Output: AC/DC 12-30V(-/+10%)
• Type of Ray: Infrared light modulation
• Photo Source: Infrared 940mm/37ft
• Light Beam: 8 channel transmit, 8 channel receive
• This product is used for the detection of existing human body and objects to prevent anti-pinch accurately. Ceiling mounted presence detector not only can be used for sliding door, revolving door but also in ATM Cabin.
• Have function of background self-learn. Can learn background automatically when power on. Suit all kinds of occasions.
• Always self-correcting once be influenced by quake, distortion, move, dark and sunshine. Ensure the sensor can work durable.

Specifications:

• Power Output: AC/DC 12-30V(-/+10%)
• Type of Ray: Infrared light modulation
• Photo Source: Infrared 940mm/37ft
• Light Beam: 8 channel transmit, 8 channel receive
• Quiescent Current: 35mA
• Working Current: 73mA
• Self-learn Time: 15s
• Operating Display: Standby—blue LED; Detecting—red LED
• Temperature Range: -40℃ ~ 60℃ / -40℉~140℉
• Maximum Installation: 2500mm
• Maximum Detection Area: 2000(W)x500(D) mm / 78.7(W)x19.7(D) inch
• Hold-up Time: 500ms
• Response Time: ≤100ms
• Dimension of Exposed: 200(L)x49(W)x32(H)mm / 7.9(L)x1.9(W)x1.3(H) inch
• Dimension of Conceal: 152(L)x38(W)x25(H)mm / 6.0(L)x1.5(W)x1.0(H) inch
• Package weight: 310g / 0.68lb

Package:

• 1 x Ceiling mounted presence detector
