20 AWG Gauge 6 Conductor Bare Copper Unshielded Alarm Security Burglar Cable Wire (100ft)

$102.00

Our quality stranded cable has copper cores and a durable, yet flexible PVC outer insulation making it ideal for any low voltage installation. It can be applied to security monitoring and alarm system, building intercom system, for electrical equipment internal line control, for signal control of computer, instrument, electronic equipment and automation equipment.

SKU: UT-20AWG-C6-100FT Category:

20 AWG Gauge 6 Conductor Bare Copper Unshielded Alarm Security Burglar Cable Wire (100ft)



Features:

  • Conductor Material: Copper (high grade)
  • Conductor Area CSA (per strand): 0.5mm² /20 AWG
  • Commonly used in security/CCTV & Access control installations. Alarm cable can be used in a wide variety of applications such as; connecting to PIR sensors, door/window contacts, linking control panels together and much more.
  • Our quality stranded cable has copper cores and a durable, yet flexible PVC outer insulation making it ideal for any low voltage installations
  • Voltage drop should be taken into consideration before installing to ensure suitability particularly if you are going over a long distance at a high current.
  • Apply to security monitoring and alarm system, building intercom system, for electrical equipment internal line control, for signal control of computer, instrument, electronic equipment and automation equipment.
  • 0.5mm² RVV 300/300V square meter copper wire cable extend RVV wire
  • PVC riser rated jacket
  • The 50ft variants in our range are hand cut to length and are not likely to be supplied on a reel.

Specifications:

  • No. of Cores: 6
  • Nominal area: 0.5mm² / 20 AWG
  • Structure of conductor (No./mm): 23/0.15
  • Lower limit of overall diameter: 6.2mm
  • Upper limit of overall diameter: 7.8mm
  • Maximum electrical resistance at 20C Ω/KM: 48.2
  • Minimum insulation resistance at 70C MΩ.KM: 0.013
  • Core Colours: White/Brown/Grey/Red/Blue/Black
  • Conductor Material: Bare copper (high grade)
  • PVC Jacket Colour: White
  • Length: 100ft
  • Applications: Access control panels, security panels, card readers, sensors, keypads, power, microphones, speakers, alarm system

Package:

  • 1 x 100ft copper wire
